bed size guide

Use this guide when ordering your Norstar truck bed. Please observe the measurements of each dimension and check before placing your order.

Length: Measurement from cab to end of frame.
Width: Measurement from outside of tire to outside of tire
CTA: Measurement from cab to axle
Runner: Measurement from outside of frame to outside of frame at the rear of the frame.
Models: ST, SF, SR, SD
Order Method: Model x Length x Width x CTA x Runner
Example: ST 9’4”L x 97”W x 60”CTA x 34” Runners (Add options) Note: 11’ long beds will have 84” CTA

‍

1998-Present

Dually – 8’6”L x 97”W x 56” CTA x 38” Runners
Single Wheel Long Wheel Base – 8’6”L x 84”W x 56”CTA x 38” Runner
Single Wheel Short Wheel Base – 84”L x 84”W x 40”CTA x 38” Runner
Cab & Chassis – 9’4”L x 94''/97”W x 60”CTA x 34” Runners
F-450 & 550 are 94” & 97”W with Standard Headache Rack
2015 F650 Runners 34.5”

‍

2001-Present

Dually – 8’6”L x 97”W x 56”CTA x 42” Runners
Single Wheel Long Wheel Base – 8’6”L x 84”W x 56”CTA x 42” Runner
Single Wheel Short Wheel Base – 84”L x 84”W x 42”CTA x 42” Runner
Cab & Chassis – 9’ 4”L x 94”/97”W x 60”CTA x 34” Runners
(Prior to 2000 measurements will be required)

‍

2003-Present

2007 Cab and Chassis – 9’4”L x 94”W x 60”CTA x 34” Runner
Mega Cab – 84”L x 97”W x 40” CTA x 42” Runners
Mega Cab – 84”L x 84”W x 38” CTA x 42” Runners
Dually – 8’6”L x 97”W x 58”CTA x 42” Runners
Single Wheel Long Wheel Base – 8’6”L x 84”W x 58”CTA x 42” Runner
Single Wheel Short Wheel Base – 84”L x 84”W x 38”CTA x 42” Runner
2002 and earlier will have 56” CTA and 38” Runners on long bed

‍

Plug N Play

Installation Adapters

The standard wire harness plug on Norstar beds will fit most GM vehicle factory harnesses. We also offer a variety of plug n play adapters that will vehicles year models by the following manufacturers:

1001010 WIRE HARNESS ADAPTER DODGE, CAB CHASS (YEAR 2000-CURRENT)
1001009 WIRE HARNESS ADAPTER FORD, CAB CHASS (YEAR 2000-CURRENT)
1001011 WIRE HARNESS ADAPTER FORD, PICK-UP BOX DELETE CURRENT (YEAR 2011-CURRENT)
1001013 WIRE HARNESS ADAPTER FORD, PICK-UP BOX DELETE w/ STOP ADAPTOR (YEAR 2011-CURRENT)
1001012 WIRE HARNESS ADAPTER GM, ADAPTER (YEAR 2015)
1001014 WIRE HARNESS ADAPTER GM, PICK-UP BOX DELETE (YEAR 2010-2014)

‍
