ETG14 Equipment Gooseneck

Specifications

WIDTH: 83
LENGTH: 20
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 6" Channel

WEIGHT: 3,760

WIDTH: 83
LENGTH: 22
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 6" Channel

WEIGHT: 3,770

‍

WIDTH: 83
LENGTH: 24
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 8" Channel

WEIGHT: 4,020

‍

WIDTH: 83
LENGTH: 26
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 8" Channel

WEIGHT: 4,310

‍

WIDTH: 83
LENGTH: 28
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 8" Channel

WEIGHT: 4,691

‍

WIDTH: 83
LENGTH: 30
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 8" Channel

WEIGHT: 4,770

‍

WIDTH: 83
LENGTH: 32
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 5,020

‍

WIDTH: 83
LENGTH: 32
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 5,156

‍

WIDTH: 83
LENGTH: 34
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 6,375

‍

WIDTH: 83
LENGTH: 36
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 6,600

‍

WIDTH: 83
LENGTH: 38
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 6,900

‍

WIDTH: 83
LENGTH: 40
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 7,400

‍

WIDTH: 83
LENGTH: 42
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 7,620

‍

WIDTH: 83
LENGTH: 44
GVWR: 21,000
AXLES: 3 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE
TONGUE: 10" Channel

WEIGHT: 7,845

‍

*Weight of units are approximates only and subject to change depending on options.

‍

*Weight of units are approximates only and subject to change depending on options.

Standard Features

10" I-Beam Neck and 12" Risers

235/80R16 Radial Tires

2 5/16" Adjustable Coupler

3" Structural Channel Crossmembers

Rub Rail and Stake Pockets

Removable Diamond Plate Fenders (83" wide)

Cambered Brake Axles

Multi-leaf Slipper Spring Suspension

E-Z Lube Hubs

2 Electric Brake Axles

5' Slide-in Ramps

2 -10k Drop-Leg Jacks

Treated Pine 2"x 8" Floor

4 Standard 3" D-Rings

Black Mod Wheels*

Locking Front Toolbox

Lifetime LED Lighting

All Lighting DOT Approved

Molded Sealed Harness with Resistors

7-Way Receiver Female Plug with Adapter

Powder Coat & Primer

‍

options

Tandem 8k Axles

102" Wide Deck

2' Dove Tail & Slide In Ramps

4' Dove Tail & Slide In Ramps

2' Dove & 5' Stand-Up Ramps

4' Dove & Rampage Ramps

Steel Floor

Fork Holders

2 Speed Drop-Leg Jacks

Winch Plate 1/2" (in neck)

Cold Weather Harness: -85°F to 221°F (Standard harness: -40°F to 158°F)

Rear Supports (5k Swivel Jacks)

Deck Over

12" Crossmembers (per ft)

Steel Floor

Blackwood Floor

Pipe Welded Sides

Jack Hydraulic Atlas Assy 2 -12k

Options gallery

Accessories/misc

Toolboxes

Ratchets

Sides

Jacks

Dove Tails & Ramps

Hydraulic Dove Options

Flooring

Accessories/misc

U52 - half inch winch plate in gooseneck

this optional feature adds a winch plate into the gooseneck of your trailer for a winch to be mounted on.

Accessories/misc

W91 - Cold Weather Harness

the cold weather harness helps keep your trailer safely operating in wintery or cold eviroments.

Dove Tails & Ramps

D03 - Dove tail with diamond plate and stand-up ramps.

Combines dovetail with diamond plating & stand-up ramps making hauling efficient and hassle free.

Dove Tails & Ramps

D12 - Stand-up ramps with straight deck

The D12 comes standard with a straight deck and 5'x18" stand-up ramps, delivering a clean, level surface with quick, ready to use loading capability.

Dove Tails & Ramps

D04/D10/D11 - Dovetail with stand-up ramps

Combines dovetail with stand-up ramps making hauling efficient and hassle free.

Dove Tails & Ramps

D05/D14 - Dovetail with Rampage Ramps

Combining the best of both worlds, this option gives you a dovetail as well as attaching our rampage ramps making for an easy loading & unloading experience. Size varies by model.

Dove Tails & Ramps

D06/D08/D09 - Dovetail w/ slide in ramps

Slide in ramps provide strength and durability while also having easily accessible storage solutions for your equipment trailer. Size availability varies by model.

Dove Tails & Ramps

D17 - Heavy Duty Stand Up Ramps

Stronger and more reinforced than our regular stand up ramps, these ramps are meant for bigger and heavier machinery & equipment Available in 2'x72".

Dove Tails & Ramps

D07/D13/D30 - Rampage Ramps

Rampage Ramps are a tough, durable option for loading and unloading your trailer. Even better they are easy to use and flip over for convenient storage when not in use. Available in 3',4',5'.

Sides

P10 - Pipe Welded Sides

Adds welded pipe sides by the foot, giving your equipment trailer extra strength, containment, and durability.

Flooring

E03 - Blackwood Flooring

Blackwood flooring by the foot, combines lasting durability with enhanced traction for safer, easier loading.

Flooring

E02 - Steel Flooring

Adds a durable steel floor by the foot, delivering superior strength and long-lasting performance for heavy-duty use.

Accessories/misc

D60 - Deck-Over Neck

An additional deck that can be added on top of any gooseneck model that provides extra loading area for small equipment items.

Accessories/misc

N02/N03 Extra D-Rings

Additional D-rings can be added for extra support, providing maximum tie-down options for safely securing equipment and cargo.

Accessories/misc

R06 - 6" Raised Gooseneck

A 6-inch raised gooseneck, improving clearance and providing a better towing angle for easier loading and transport. Perfect for trucks with a large lift.

Jacks

J52/J56 - 12k Hydraulic Jack (if hydraulics NOT equipped)

Available in either a single or set of 2, our 12,000 lb hydraulic jacks ensuring strong, dependable litting capability for safe operation.

Jacks

J55 - 2 Speed Jacks

These jacks feature a 2-speed system, allowing faster setup and precise control for safely lifting and stabilizing trailers.

reviews

4.0

5.0

1k reviews

3.0

2.0

1.0

ETG

I needed to upgrade from a 7k to a 10k equipment trailer and the Iron Bull ETB10 fit the bill. The extras like the D rings and removable fenders are great and the overall build quality is awesome. Ive towed it all up and down the east coast with no issues. I would definitely recommend.

-Bryan B.

09/11/24

View All

83" wide or 102" wide Iron Bull equipment goosenecks are a great addition to any farm or fleet. With two 7k axles and tons of standard features, Iron Bull equipment Goosenecks are a great addition to any farm or jobsite.

‍
