0.9
13
13
TLG14
83 x 16--26'
SIZES
9,990 -- 14,000 lb
GVWR
2 x 5,200 | 2 x 7,000 lb
AXLES
TLG14
TLG 14k Low Pro Gooseneck Tilt
No items found.
Low-Pro Gooseneck Tilt Trailer
SIZES
83 x 16--26'
GVWR
9,990 -- 14,000 lb
Iron Bull Trailer Manufacturing is excited to announce the addition of Low Profile Gooseneck Tilts to their product lineup. These trailers are vailable in 16’-24’ lengths with gravity tilt or full power up and down. Tandem and triple axle configurations are also available.

When you think of trailers, you think about loading and unloading - and this has to be one of the easiest trailers to load and unload in our lineup. Combine the 20 inch deck height, full 83 inches between the fenders, and 11 degree loading angle with the versatility of a gooseneck and a ton of options, and you have a trailer that can make just about any job easier. This trailer is virtually jack of all trades for any home or business.

Tilt Deck offers an alternative to ramps, featuring 20 inch deck height, full 83 inches between the fenders, and 11 degree loa

* Please be sure and verify your truck bed deck height to make sure it is compatible with the height of the gooseneck.

REQUEST A QUOTE
add review
reviews
4.0
.
.
5.0
1k reviews
4.0
1k reviews
3.0
1k reviews
2.0
1k reviews
1.0
1k reviews
072
TLG
Specifications

WIDTH: 83
LENGTH: 16
GVWR: 9,900
AXLES: 2 x 5,200 lb
TIRE/WHEEL: 225/75R16 6 HOLE

STATIONARY: 0' (Power Tilt Only)
WEIGHT: 3,200



WIDTH: 83
LENGTH: 18
GVWR: 9,900
AXLES: 2 x 5,200 lb
TIRE/WHEEL: 225/75R16 6 HOLE

STATIONARY: 2'
WEIGHT: 3,400

WIDTH: 83
LENGTH: 20
GVWR: 9,900
AXLES: 2 x 5,200 lb
TIRE/WHEEL: 225/75R16 6 HOLE

STATIONARY: 4'
WEIGHT: 3,500

WIDTH: 83
LENGTH: 22
GVWR: 9,900
AXLES: 2 x 5,200 lb
TIRE/WHEEL: 225/75R16 6 HOLE

STATIONARY: 6'
WEIGHT: 3,600

WIDTH: 83
LENGTH: 18
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE

STATIONARY: 2'
WEIGHT: 3,700

WIDTH: 83
LENGTH: 20
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE

STATIONARY: 4'
WEIGHT: 3,800

WIDTH: 83
LENGTH: 22
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE

STATIONARY: 6'
WEIGHT: 4,000

WIDTH: 83
LENGTH: 24
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE

STATIONARY: 8'
WEIGHT: 4,200

WIDTH: 83
LENGTH: 23
GVWR: 14,000
AXLES: 2 x 7,000 lb
TIRE/WHEEL: 235/80R16 8 HOLE

STATIONARY: 10'
WEIGHT: 4,400

*Weight of units are approximates only and subject to change depending on options.

*Weight of units are approximates only and subject to change depending on options.
Brochures
No items found.
Standard Features

10" I-Beam Neck

10" I-Beam Frame

2 5/16" Adjustable Coupler

3" Channel Crossmembers

2" x 6" Tubing Frame

1/8" Removable Diamond Plate Fenders

Knife Edge Tail w/ 11 degree Load Angle

Cambered Brake Axles

Torsion Suspension

E-Z Lube Hubs

2 Electric Brake Axles

2 - 10k Drop Leg Jacks

Lockable Full Neck Width Tool Box

Safety Chains 32" X 5/16" G#70 (18,800Lb)

Treated Pine 2" x 8" Flooring

4 Standard 3" D-Rings

285/80R16 Brand Radial Tires

Sealed Lifetime LED D.O.T. Approved Lighting

7 Way Receiver Female Plug w/ Adaptor

Powder Coat

options

Power up / Power down

Full Deck Tilt

102" Wide Deck (83" between Fenders)

Steel Floor

14 Ply Tires

12" Cross Members

LED Backup Lights

Winch Plate 1/2"

Cold Weather Harness

Front Tool Box (Available on Gravity Only) Standard on Full Power

Additional D-Rings

Weld-on Spare Tire Mount

Bolt-on Spare Tire Mount

Spare Tire 10 Ply

Spare Tire 14 Ply

bed size guide
Use this guide when ordering your Norstar truck bed. Please observe the measurements of each dimension and check before placing your order.
  • Length: Measurement from cab to end of frame.
  • Width: Measurement from outside of tire to outside of tire
  • CTA: Measurement from cab to axle
  • Runner: Measurement from outside of frame to outside of frame at the rear of the frame.
  • Models: ST, SF, SR, SD
  • Order Method: Model x Length x Width x CTA x Runner
  • Example: ST 9’4”L x 97”W x 60”CTA x 34” Runners (Add options) Note: 11’ long beds will have 84” CTA
